The Gridfinity Layout Tool is a free, browser-based application designed to help users plan and create modular storage solutions using the Gridfinity system. It features a bin generator, baseplate customization, and a layout planner with 3D preview and print list export capabilities. The tool supports various file formats and is accessible without an account or installation.
- ▪The tool allows users to generate custom Gridfinity bins with options for compartments, wall cutouts, and label tabs.
- ▪Baseplates can be customized with magnet holes and connector nubs, and are automatically split to fit print bed sizes.
- ▪The layout planner prevents bin overlaps, supports layered and color-coded organization, and exports a print list with filament estimates.
Opening excerpt (first ~120 words) tap to expand
<style>#seo-fallback{display:block!important}</style> Gridfinity Layout Tool A free tool for making Gridfinity bins and planning drawer layouts. Runs in your browser — nothing to install. Bin Generator The built-in bin generator lets you set dimensions, pick a base style, add compartments, and download the file as STL, STEP, or 3MF. Other features: wall cutouts, scoop ramps, label tabs, honeycomb wall patterns, and a pen tool for drawing freeform cutouts. Baseplate Generator Generate custom baseplates sized to your drawer. Configure magnet holes, connector nubs, and per-side edge padding. Large baseplates split automatically to fit your print bed. Export as STL, STEP, or 3MF. Layout Planner Measure your drawer, set the grid size, and drag to place bins.
…
